Operating elements for driving
3.2 Brief description of the operating elements
Operating manual 3 302 819 en 3 - 67
GMK3060
13.12.2018
3.2.15 Suspension
CCS display
Suspension display
Suspension on/off
Suspension operation pressure gauge
– Switch on: Select symbol (1) and confirm – Symbol (2) green
Suspension on – enabled for on-road driving
– Switch off Select symbol (1) and confirm – Symbol (2) red
Suspension off – blocked for crane operation
à p. 5 - 16
1 Suspension pressure for 1st and 2nd axle line to the left
2 Suspension pressure for 1st and 2nd axle line to the right
3 Suspension pressure for 3rd to 5th axle line to the left
4 Suspension pressure for 3rd to 5th axle line to the right
