Malfunctions during crane operation
14.5 Emergency operations and programs
14 - 48 3 302 819 en Operating manual
GMK3060
13.12.2018
14.5.5 Notes on slewing in emergency operation
For the Standard
slewing range
type
If the MAXbase slewing range type is activated; Ã p. 14 - 49.
Slewing is not monitored by the RCL in emergency operation.
G
Risk of overturning when slewing in emergency operation!
Check the table to see if slewing is permitted. Adhere to the enabled working
range specified in the Lifting capacity table and observe the restrictions described.
If you have any doubts, contact
Manitowoc Crane Care.
Rigged outrigger span 6.825 x (22.4 x)
6.200 m
20.3 ft)
4.400 m
(14.4 ft)
2.320 m
(7.6 ft)
Free on
wheels
Rigged counterweight
6.6 t
(14,500 lbs)
7.6 t
(16,700 lbs)
Slewing permitted
1)
8.6 t
(18,900 lbs)
2)
9.6 t
(21,100 lbs)
Slewing
not
permissi-
ble
2)
Slewing
not
permissi-
ble
3)
10.6 t
(23,300 lbs)
11.6 t
(25,500 lbs)
12.6 t
(27,700 lbs)
13.6 t
(29,900 lbs)
1)
Slewing only permitted if the working radius permitted in the working range
is observed;
à Lifting capacity table
2)
Only 0° operating position to the rear permitted
3)
Rigging modes not permitted
