Rigging work
12.6 Rigging/unrigging the counterweight
12 - 76 3 302 819 en Operating manual
GMK3060
13.12.2018
12.6.12 Slewing with a rigged counterweight
Slewing with a rigged counterweight is only permissible when:
– The necessary outrigger span is rigged
– The current rigging mode is shown on the RCL display and
– The permissible working radius according to Lifting capacity table is maintained.
G
Danger of overturning when slewing with an incorrectly set RCL!
The RCL only disables the slewing operation if you have entered the RCL code
correctly and if the RCL is not overridden.
Before slewing, always check that the current rigging mode is shown on the
RCL display.
This prevents slewing operations from being enabled within the impermissible
ranges, which would cause the truck crane to overturn.
G
Risk of overturning when slewing in emergency operation!
Crane operations are not monitored by the RCL whilst the hand-held control is
connected during emergency operation!
Various checks are therefore necessary, depending on the active slewing range
type, before slewing in emergency operation;
à p. 14 - 48.
