Operating elements for crane operation
9.2 Brief description of the operating elements
9 - 148 3 302 819 en Operating manual
GMK3060
13.12.2018
9.2.27 Diagnostics
The diagnostics connections may only be operated by the service personnel.
The following connections are below the
cover (3).
Additional diagnostics and service connections
are present on the CCS and RCL control units (4).
• Do not connect external devices, e.g. a mobile
phone, to these connections!
9.2.28 Other
Disclaimer menu
1 CCS diagnostics –
(serial interface)
2 CCS diagnostics – CAN bus
S
Risk of damage to the crane control system!
Do not connect external devices to the diagnostic connections. This prevents
severe malfunctions in the crane control system.
– Opening: Select and confirm symbol (1). The warranty waiver text is
shown on the display.
