Driving mode
5.5 Separate steering
Operating manual 3 302 819 en 5 - 67
GMK3060
13.12.2018
Steering with separate steering – automatic
• Steer the 1st axle lines with the steering wheel.
(A) – When driving around corners
The 2nd and 3rd axle lines are steered out in line
with the turning radius, against the steering angle
on the 1st axle line.
(B) – For crab travel mode
The 2nd and 3rd axle lines in the same direction
as the 1st axle line.
Steering with manual separate steering
• Steer the 1st axle lines with the steering wheel.
• Steer the 2nd to 3rd axle lines with the button (1).
The axle lines are steered as long as you keep the button pressed or until an end
position is reached.
(A) – For driving around corners
• Steer the 2nd and 3rd axle line opposite to the
1st axle line.
(B) – For crab travel mode
• Steer the 2nd and 3rd axle lines in the same
direction as the 1st axle line.
– To turn to the left: • Press the button in at the left.
– To turn to the right:
• Press button to the right.
