Driving modes
6.1 Driving modes
Operating manual 3 302 819 en 6 - 3
GMK3060
13.12.2018
6.1.2 Table for a maximum axle load of 12 t (26,500 lbs)
Tyres
385/95 R25
Also be aware of the effects on the axle loads when towing a trailer; à p. 5 - 81.
s
Driving mode
12345678910
Equipment
385/95 R25 tyres ✔✔✔✔✔✔✔✔✔✔
Drive 6 x 4 x 6 ✔✔✔✔✔✔✔
Drive 6 x 6 x 6 ✔✔✔
Towbar coupling ✔✔✔
Retarder ✔✔✔ ✔✔✔
Auxiliary hoist installed ✔✔✔✔
Rigging mode
385/95 R25 spare wheel on rear ●●●●
3 -sheave hook block attached to the
bumper
1)
●●●●●●●
1 -sheave hook block attached to the
bumper
1)
●●●
15 m (49 ft) lattice extension folded to
the side
●●●●●● ●
6.6 t counterweight attached to the
turntable
●●●●
7.6 t counterweight attached to the
turntable
●●●● ●●
1 t base plate on the counterweight
platform
●●
1) The weight of the hook blocks is based on the information in this operating
manual;
à p. 1 - 10.
