Rigging work
12.6 Rigging/unrigging the counterweight
Operating manual 3 302 819 en 12 - 59
GMK3060
13.12.2018
5. Unlock the lifting cylinders – to the end position Unlocked;
à Locking/Unlocking the counterweight, p. 12 - 71.
6. Retract the lifting cylinders – to the end position Retracted;
à Extending/retracting the lifting cylinders, p. 12 - 69.
7. Enter and confirm the current rigging mode with the currently rigged counter-
weight combination;
à p. 11 - 36.
8. Unlock the turntable;
à p. 11 - 18.
9. Lift the counterweight sections off the counterweight platform, as required by
the respective driving mode;
à Slinging points on the counterweight sections, p. 12 - 55,
à Driving modes, p. 6 - 1.
