Motorola MCS 2000 User Manual

96
VRM100 Options From the MAIN MENU, press F4, F3, F2 and then F5 to access this
screen.
This screen can be accessed only when the VRM100 capable field is set to
Enabled on the RADIO WIDE OPTIONS screen (F4/F3/F2). This screen
allows you to define and modify VRM100 radio options. Press Tab to
select the desired field, or press the desired function key (F1 - F10).If a
field is highlighted, use the UP/DOWN arrow keys to select the desired
choice or value.
Field Definitions
Disconnect On Data Use the UP/DOWN arrow keys to enable/disable this option. If this
field is enabled, the radio will send a disconnect tone at the end of data
transmission.
The default is Disabled.
Data On Failsoft Use the UP/DOWN arrow keys to enable/disable this option. If this
field is enabled, the radio will permit data transmit/receive on Failsoft.
The default is Enabled.
Speaker Unmute On Data Use the UP/DOWN arrow keys to enable/disable this option. If this
feature is enabled, the speaker will unmute while data is being
received.
The default is Disabled.
Transmit Enable Polarity Use the UP/DOWN arrow keys to select Active High or Active Low.
This value in this field determines the polarity of the output signal
TXE.
The default is Active High.
DCBE
MOTOROLA Radio Service Software Use UP/DOWN Arrows to Select Choice.
MCS Model:
...CONFIG:RADIO OPTIONS:VRM OPTIONS
VRM100 OPTIONS
--------------
Disconnect On Data................Disabled
Data On Failsoft...................Enabled
Speaker Unmute On Data............Disabled
Transmit Enable Polarity.......Active High
Channel Grant Polarity.........Active High
Data Mode Request Polarity......Active Low
MLU Operation.....................Disabled
Data Overrides Voice..............Disabled
Ignore Data Display...............Disabled
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP EXIT
