Service Menu Press F2 at the MAIN MENU to access the SERVICE MENU.
All radio alignment and board replacement procedures are accessed
from this menu. A radio must be connected to your computer using a RIB
and cables and the radio turned on before you will be permitted to access the
service screens.
Refer to your Radio Service Manual for detailed service procedures.
Note: If the radio connected to the RIB is a CBI-initialized radio and
you press F2, F3 or F4 in the SERVICE MENU, the RSS will display
the following pop-up message: “!!!Warning!!! You cannot read,
program, or tune a CBI radio until you initialize it.” Press F9 to
initialize the radio.
Note: If the radio connected to the RIB is NOT a CBI-initialized radio
and you press F9 from the SERVICE MENU, the RSS will display the
following pop-up message: “!!!Warning!!! The radio attached to
the RIB is not a CBI-initialized radio.”
B
MOTOROLA Radio Service Software Select Function F1 - F10.
MCS Model:
Read Radio Completed Successfully.
MAIN:SERVICE
SERVICE MENU
------------
F1 - HELP
F2 - Transmitter Alignments
F3 - Receiver Alignments
F4 - Signalling Alignments
F5 -
F6 -
F7 -
F8 -
F9 - Controller Board Initialization Program
F10 - Exit, Return to Main Menu
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP TX RX SIGNAL BOARD EXIT
ALIGN ALIGN ALIGN INITIALIZE
!
Caution
Do NOT switch radios in the middle of any SERVICE
procedure. Always use the EXIT function key (F10) to
return to the MAIN MENU before disconnecting the
radio. Improper exits from service screens may leave
the radio in an improperly configured state, resulting in
seriously degraded radio or system performance.
