40
Transmitter
Alignment Menu
From the MAIN MENU, press F2 twice to access the TRANSMITTER
ALIGNMENT MENU.
Standard periodic alignment procedures are performed from this
menu. Refer to your Radio Service Manual for alignment procedures.
The following alignment procedures must be performed every time
the modulation circuitry is replaced:
❒ Modulation Balance
❒ Modulation Limit: VCO Attenuator
❒ Modulation Limit: Reference Attenuator
In addition, signalling deviation for DTMF, MDC, Single Tone,
SECURE and High-Speed Trunking Data should be checked every time
the radio is serviced. Prior to adjusting signalling deviation, radio
compensation/deviation adjustments must be made. No adjustments
are required for DPL, PL or Trunking Connect Tone Deviation.
BB
MOTOROLA Radio Service Software Select Function F1 - F10.
MCS Model:
...SERVICE:TRANSMITTER ALIGNMENT MENU
TRANSMITTER ALIGNMENT MENU
--------------------------
F1 - HELP
F2 - Reference Oscillator
F3 - Tx Power
F4 - Tx Deviation Balance (Compensation)
F5 - Tx Deviation Limit
F6 - Tx Deviation Limit: Reference
F7 -
F8 - Secure Tx Deviation
F9 - Tx Current Limit
F10 - Exit, Return to Service Menu
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP REF TX DEV DEV REF SECURE CUR EXIT
OSC PWR BAL LIMIT ATTEN DEV LIMIT
!
Caution
These procedures should be attempted only by
qualified service personnel. Failure to perform
alignment procedures properly may result in seriously
degraded radio or system performance.
