Zone/Talkgroup
Assignment
At the MAIN MENU, press F4 and then F8 to access this screen.
A zone is an artificial grouping of channels (or talkgroups) to permit
ease of operation. Generally, all members of a zone will reflect some
common characteristic such as geographic location, job function,
signalling type, etc.
Each member of a zone is defined by selecting a Conventional
personality, or a Trunking personality and a talkgroup. On radios
equipped with a display, an optional name can also be assigned to each
member of the zone. Each zone can also be named. The number of
characters allotted for the zone name versus the channel name is
defined on the RADIO WIDE DISPLAY OPTIONS screen (F4/F3/F6).
Zones and channels can be added and deleted using the F2/F5 keys.
Zone selection may be via the rotary switch, the toggle switch or the
keypad (if applicable).
Press Tab to select the desired field, or press the desired function key
(F1 - F10). If a field is highlighted, use the UP/DOWN arrow keys to
select the desired choice or value.
Function Key Descriptions
F2 - ADD ZONE Adds a zone.
F3 - PREV ZONE Accesses the previous zone.
F4 - NEXT ZONE Accesses the next zone.
F5 - DELETE ZONE Deletes a zone. You will be prompted for confirmation before the zone
is actually deleted.
F6 - ADD CHAN Adds a channel.
F7 - DELETE CHAN Deletes a channel. You will be prompted for confirmation before the
channel is actually deleted.
DH
MOTOROLA Radio Service Software Enter or Scroll to Select Value.
MCS Model:
MAIN:CHANGE/VIEW:ZONE/CHAN
Zone Number... 1 ZONE/TALKGROUP (CHANNEL) ASSIGNMENT
-----------------------------------
Zone Name.Z1
Personality Talkgroup
Channel Number Channel Name Type Number Number Strapping
-------------- ------------ -------------- --------- ---------
1 CHAN 1 Conv 1
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP ADD PREV NEXT DELETE ADD DELETE EXIT
ZONE ZONE ZONE ZONE CHAN CHAN
