22
Service Software
Configuration
The SERVICE SOFTWARE CONFIGURATION screen can be accessed by
pressing F9 at the MAIN MENU.
From this screen, you may set up the paths for archive files. You may
also set up the serial port (COM 1, COM 2, COM 3 or COM 4) that will
be used to communicate with the radio.
Function Key Descriptions
F3 - CONFIGURE PC Brings up a screen where you may set default disk drive paths for
archive and back-up files. It is also used to select the asynchronous
communications port (COM 1, COM 2, COM 3 or COM 4) to which
the RIB will be connected. The RSS will automatically determine at
what clock speed the computer is operating. No user-selectable
parameters are required.
Note: Refer to the owner’s manual that came with your
computer for a completes description of path names and
asynchronous communication ports.
F7 - SCREEN COLORS Brings up a screen where you may enable or disable the color display
option and specify colors for different parts of the RSS screen (if color
display is enabled). If the computer is capable of color display, viewing
quality is greatly enhanced. The standard default configuration for the
RSS is for a monochrome display.
I
MOTOROLA Radio Service Software Select Function F1 - F10.
MCS Model:
MAIN:CONFIGURATION
SERVICE SOFTWARE CONFIGURATION
------------------------------
F1 - HELP
F2 -
F3 - PC CONFIGURATION: Drives, Paths, Ports, etc.
F4 -
F5 -
F6 -
F7 - SCREEN Color Configuration
F8 -
F9 -
F10 - Exit, Return to Main Menu
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP CONFIGURE SCREEN EXIT
PC COLORS
