240
Single Tone Systems From the MAIN MENU, press F4, F6, F7 and then F2 to access this
screen.
This screen allows you to change/view the parameters that pertain to
a Single Tone System. Press Tab to select the desired field, or press the
desired function key (F1 - F10). If a field is highlighted, use the UP/
DOWN arrow keys to select the desired choice or value.
Function Key Descriptions
F2 - ADD SYS Adds a system.
F3 - PREV SYS Accesses the previous system.
F4 - NEXT SYS Accesses the next system.
F5 - DELETE SYS Deletes a system. You will be prompted for confirmation before the
system is actually deleted.
Field Definitions
System Use the UP/DOWN arrow keys to select the desired Single Tone system,
enter the system number directly, or use the F3/F4 function keys to
scroll through the available systems. The radio may have a maximum of
16 systems.
Tone Pretime (ms) Use the UP/DOWN arrow keys to select or directly enter the desired
value. The Tone Pretime for Tone Signalling specifies the length of
time that “dead” carrier is transmitted between the initiation of the
Tone (RAC) transmission and the actual Tone (RAC) transmission. The
valid range of values is 25 to 6375 ms in 25-ms increments.
The default is 250.
DFGB
MOTOROLA Radio Service Software Enter or Scroll to Select System.
MCS Model:
...CONV:AUX:SINGLETONE SYSTEM
System............ 1
SINGLETONE SYSTEM
-----------------
Tone Pretime (ms)........................250
Tone Duration (ms).......................500
PTT Sidetone.........................Enabled
RAB Sidetone.........................Enabled
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP ADD PREV NEXT DELETE EXIT
SYS SYS SYS SYS
