201
MPL List
Configuration
From the MAIN MENU, press F4, F6, F2, and then F2 to access this
screen.
The MPL Configuration screen is used to change/view the parameters
that pertain to the MPL List which is used with the User-Selectable PL
(MPL) feature in the Conventional Personality Options Screen (Main-
>F4->F6->F3->F9). To print the MPL List, press F2 from the Print
Conventional Menu Screen (Main, F5, F6).
Function Key Descriptions
F2 - ADD MPL ADD MPL is used to add another MPL entry to the MPL List. A total of
16 MPL entries are allowed.
F3 - PREV MPL PREVIOUS MPL is used to navigate to the previous MPL entry while
remaining in the same data field.
F4 - NEXT MPL NEXT MPL is used to navigate to the next MPL entry while remaining
in the same data field.
F5 - DELETE MPL DELETE MPL is used to remove the current MPL entry from the MPL
list.
Field Definitions
MPL Number This field selects an available MPL entry. Alternately, the F3/F4
function keys can be used to navigate through the MPL entries.
MPL Name The MPL names will ONLY be displayed when viewing or changing the
radio's currently selected MPL.
Enter the alphanumeric text that will appear on the radio display for
this MPL entry. The maximum number of characters will vary based
on the radio model.
Squelch Type Refer to the Conventional Personality Screen’s Field Definitions.
DFBB
MOTOROLA Radio Service Software Enter or Scroll to Select List.
MCS Model:
MAIN:CHANGE/VIEW:CONV:WIDE OPTIONS:MPL
MPL LIST CONFIGURATION
----------------------
MPL Number........ 1 MPL Name.................MPL 1
Receive Transmit Direct
Squelch Type CSQ Disabled Disabled
Code
DPL Invert
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP ADD PREV NEXT DELETE EXIT
MPL MPL MPL MPL
