Motorola MCS 2000 User Manual

106
Radio Wide
Button
Configuration
At the MAIN MENU, press F4, F3 twice, and then F2 to access this
screen.
Hand-Held Control Head Button Configuration Screen
There are four screens in the RSS which pertain to Radio Wide button
configuration. You may or may not be able to access some or all these
screens based on the model of the current radio (or codeplug) and the options
ordered with it.
Control Head C Button Configuration Screen
This screen is used to assign the features to specific buttons. Use the
UP/DOWN arrow keys to select the desired function for this button
and then use the Enter (Carriage Return) or Tab key to advance to the
next button position. Use Shift-Tab to back up to the previous button
position.
DCCB
MOTOROLA Radio Service Software Use UP/DOWN Arrows to Select Choice.
MCS Model: M01KHH9PW5AN
..CHANGE/VIEW:CONFIG:FEATURES:BUTTONS
_ PWR ___[Unpr]___[Unpr]_____ TOP BUTTONS
HAND HELD
CONTROL HEAD / Ctrl Head Display
|
| [Unpr]
PTT| [Unpr] [Unpr] [Unpr] SIDE
| [Unpr] [Unpr] [Unpr] [Unpr] BUTTONS
|
\ <MIC> VolUp [ChUp] [Unpr]
VolDn [ChDn]
1 [Unpr] 2 [Unpr] 3 [Unpr]
4 [Unpr] 5 [Unpr] 6 [Unpr]
7 [Unpr] 8 [Unpr] 9 [Unpr]
__*________0________#________
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP EXIT
MOTOROLA Radio Service Software Use UP/DOWN Arrows to Select Choice.
MCS Model: M01KHL9PW4AN
..CHANGE/VIEW:CONFIG:FEATURES:BUTTONS
CONTROL HEAD - C
|----------------------------------------------------------------------------|
| |
| |--------------------------------| [ChUp] |
| | | |
| PWR | CONTROL HEAD BUTTONS | |
| | | [ChDn] |
| |--------------------------------| |
| |
| [Unpr] [Unpr] [Unpr] [Menu] [ Sel] |
|----------------------------------------------------------------------------|
| UP MIDDLE DOWN |
| MICROPHONE BUTTONS [Unpr] [Unpr] [Unpr] |
|----------------------------------------------------------------------------|
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP EXIT
