56
Rated Audio
Alignment
From the MAIN MENU, press F2, F3 and then F3 to access this screen.
This alignment is required every time the Controller Board or the RF Board
is replaced or serviced. This procedure adjusts for rated audio power
across the radio speaker.
Refer to your Radio Service Manual for the Rated Audio Calibration
procedure.
Programming Procedure 1. Apply the appropriate RF signal to the radio.
2. Modify the Rated Audio Volume Softpot setting using the UP/
DOWN arrow keys.
3. Press F8 to save the new values.
Function Key Descriptions
F8 - PROGRAM VALUE Programs the selected value into the radio.
Field Definition
New Softpot Value This is the softpot value for this frequency. The status bar shows the
relationship between this setting and the minimum and maximum
settings.
Std. Audio This is the working rated volume softpot value. The status bar shows
the relationship between this setting and the minimum and
maximum settings.
BCC
MOTOROLA Radio Service Software Use UP/DOWN Arrows To Adjust Softpot.
MCS Model:
..RECEIVER ALIGNMENT MENU:RATED AUDIO
RATED AUDIO
-----------
Frequency Current Value New Softpot Value
--------- ------------- -----------------
167.5625 Std. Audio.......230 Std. Audio.......230
0 255
MIN |----+----+----+----+----+----+----+----+----+----+---X+----| MAX
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP PROGRAM EXIT
VALUE
!
Caution
This procedure should be attempted only by qualified
service personnel. Failure to perform alignment
procedures properly may result in seriously degraded
radio or system performance.
