246
Quik-Call II System
Options
From the MAIN MENU, press F4, F6, F7, F4 and then F9 to access this
screen.
A system or FTR key is required to access this screen. This screen allows you
to change/view additional Quick-Call II system parameters. Press Tab
to select the desired field, or press the desired function key (F1 - F10).
If a field is highlighted, use the UP/DOWN arrow keys to select the
desired choice or value.
Function Key Descriptions
F3 - PREV SYS Accesses the previous Quik-Call system.
F4 - NEXT SYS Accesses the next Quik-Call system.
Field Definitions
System Use the UP/DOWN arrow keys to select the desired Quik-Call II
system. You may enter a number directly or make your selection using
the F3/F4 function keys. The radio may have a maximum number of 15
systems.
Inter-Tone Duration (sec) Use the UP/DOWN arrow keys to scroll through the available choices
or directly enter the desired value. This is the maximum time duration
allotted to detect the second tone of a two-tone sequence. This time
period begins with the detection of the first tone of the sequence. The
valid range of values is 1 to 6 seconds in 100-ms increments.
The default is 2 seconds.
Observ Window Dur (cycles) Use the UP/DOWN arrow keys to scroll through the available choices
or directly enter the desired value. This field is used to specify the
number of clock cycles in an observation window divided by four. This
calculation is used to keep the value within an integer size field.
The default is B400.
DFGDI
MOTOROLA Radio Service Software Enter or Scroll to Select System.
MCS Model:
...AUX:QUIK-CALL II SYSTEM:OPTIONS
System.............1
QUIK-CALL II SYSTEM OPTIONS
---------------------------
Inter-Tone Duration (sec)................2.0
Observ Window Dur (cycles)..............B400
Detections Required........................6
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP PREV NEXT EXIT
SYS SYS
