234
MDC System
Remote Options
From the MAIN MENU, press F4, F6, F4, F3, F9 and then F9 to access
this screen.
This screen allows you to change/view parameters pertaining to the
MDC system remote capabilities of the radio.
Function Key Descriptions
F3 - PREV SYS Is used to navigate to the previous MDC System while remaining in
the same data field.
F4 - NEXT SYS NEXT SYS is used to navigate to the next MDC System while
remaining in the same data field.
Field Definitions
MDC System This is the number of the MDC system. Use the UP/DOWN arrow keys
to change the system, or directly enter the number of the system.
Remote Mon/Radio Trace Use the UP/DOWN arrow keys to enable/disable the MDC Remote
Monitor/Radio Trace feature. When the MDC Remote Monitor/Radio
Trace feature is enabled, the radio will be able to decode an MDC
Remote Monitor or Radio Trace command sent from the dispatch
console. After decoding this command, the radio will key-up its
transmitter for a time period calculated using the 'Tx Base Time' and
another value embedded within the Remote Monitor/Radio Trace
command. The factory default is Disabled.
Remote Radio Mode Use the UP/DOWN arrow keys to select the MDC Decode Operation.
The MDC Decode Operation allows the radio to operate in one of two
possible states when it decodes an MDC Remote Monitor/Radio Trace
command:
- Radio Trace - The radio will automatically key-up sending
unmodulated carrier.
- Remote Monitor - The radio will automatically key-up and
unmute the microphone thus sending voice on the channel.
DFDCI
I
MOTOROLA Radio Service Software Enter or Scroll to Select System.
MCS Model:
...MDC:SYSTEMS:OPTIONS:REM OPTIONS
MDC System.........1
MDC SYSTEM REMOTE OPTIONS
-------------------------
Remote Mon/Radio Trace.....Enabled
Remote Radio Mode..Remote Monitor
Tx Base Time (sec).............10
Rx Base Time (sec).............10
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP PREV NEXT EXIT
SYS SYS
