54
Receive Alignment
Menu
From the MAIN MENU, press F2 and then F3 to access this screen.
Standard periodic receiver alignment procedures are performed from
this menu. Refer to your Radio Service Manual for Receive Alignment
procedures.
Function Key Descriptions
F2 - F9 Refer to your Radio Service Manual for these alignment procedures. Do
NOT attempt these procedures unless you are a qualified service person.
Note: The VRM500 Rx DISCRIMINATOR LEVEL screen can be
accessed only if the current radio model is VRM500-capable.
BC
MOTOROLA Radio Service Software Select Function F1 - F10.
MCS Model:
MAIN:SERVICE:RECEIVER ALIGNMENT MENU
RECEIVER ALIGNMENT MENU
-----------------------
F1 - HELP
F2 - Front End Bandpass Filter
F3 - Rated Audio Calibration
F4 - Squelch Attenuator (12.5kHz)
F5 - Squelch Attenuator (20kHz)
F6 - Squelch Attenuator (25/30kHz)
F7 - RSSI Alignment
F8 - Secure Rx Discriminator Level
F9 - VRM500 Rx Discriminator Level
F10 - Exit, Return to Service Menu
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP FRONT END AUDIO SQUELCH SQUELCH SQUELCH RSSI SECURE VRM500 EXIT
FILT ALGN 12.5kHz 20kHz 25/30kHz ALGN DISCR
!
Caution
This procedure should be attempted only by qualified
service personnel. Failure to perform alignment
procedures properly may result in seriously degraded
radio or system performance.
