256
Print Menu At the MAIN MENU, press F5 to access the PRINT MENU.
Make sure you have read a codeplug file using the GET/SAVE functions
before you attempt to print configuration information. The PRINT function
is used to produce permanent records of codeplug configurations. A
printer is required and should be connected to your computer
according to instructions in the user’s manual that came with your
computer. Graphics capability is NOT required.
Note: When printing, misalignment of page breaks may result if the
printer is not set up properly. For best results, configure the printer
as an IBM ProPrinter or an Epson FX/MX having factory default
settings. The default number of lines per page is 66.
Function Key Descriptions
F3 - RADIO CONFIG
(Radio Configuration)
Brings up a screen from which you can print a summary of Radio
Configuration information, including Button and Switch settings,
Phone Lists, Scan Lists, and Display information.
F4 - TRUNK DATA
(Trunking Data)
Brings up a screen from which you can print a summary of Trunking
information including personalities, call lists, and options.
F6 - CONV DATA
(Conventional Data)
Brings up a screen from which you can print out a summary of
Conventional Personality and MDC system information.
F8 -ZONE/CHANNEL ASSIGN
(Zone/Channel Assignment)
Prints out a summary of current Zone/Channel Assignment
information for the radio.
F9 - DATA SUMMARY (Radio
Codeplug Data Summary)
Prints a summary of key radio programming parameters.
E
MOTOROLA Radio Service Software Select Function F1 - F10.
MCS Model:
MAIN:PRINT
PRINT MENU
----------
F1 - HELP
F2 -
F3 - Radio Wide Buttons, Switches, Display, Scan, Phone
F4 - Trunking Systems, Personalities, Call Lists, Options
F5 -
F6 - Conventional Systems, Personalities, MDC, Options
F7 -
F8 - Zone/Channel Assignment
F9 - Radio Codeplug Data Summary
F10 - EXIT, Return to Main Menu
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP RADIO TRUNK CONV ZONE/CHN DATA EXIT
CONFIG DATA DATA ASSIGN SUMMARY
