117
DEK Configuration At the MAIN MENU, press F4, F3 twice, and then F5 to access this
screen.
DEK Configuration Screen
The Direct Entry Keypad (DEK) screen is used to specify the number of
DEK boxes that are connected to the radio and to program each DEK
button to have a specific function.
DEK boxes allow the radio to effectively have more programmable
features and to access these features with a single button press.
Function Key Definitions
F2 - ADD DEK BOX ADD DEK BOX allows you to add a DEK Box with 8 buttons. A
maximum of three DEK boxes may be added.
F5 - DELETE TOP DEK BOX Delete Top Dek Box deletes the top DEK Box. In other words, if there
are two DEK Boxes, pressing F5 will delete DEK B, regardless of where
the cursor is currently positioned.
Field Definitions
Number of DEK Boxes Number of DEK Boxes is a view-only field that displays the number of
DEK boxes connected to the radio. Each DEK box represents a group
of eight DEK buttons. This field will change as DEK boxes are added or
deleted by using the F2 and F5 function keys. The minimum number
of DEK boxes is 0. The maximum number of DEK boxes is 3.
The factory default is 0.
DEK Buttons Use the UP/DOWN arrow keys to select the desired function for this
button and then use the Enter (Carriage Return) or Tab key to advance
to the next button position. Use the Shift Tab to backup to the
previous button position. The features available on the DEK buttons
are the same as those available on the Control Head Buttons ( see the
Radio Wide Button Configuration Screen).
DCCE
MOTOROLA Radio Service Software Use UP/DOWN Arrows to Select Choice.
MCS Model:
MAIN:CHANGE/VIEW:CONFIG:FEATURES:DEK
Number of DEK boxes...3 DEK BUTTON CONFIGURATION
DEK C [Blnk ] [Blnk ] [Blnk ] [Blnk ] [Blnk ] [Blnk ] [Blnk ] [Blnk ]
DEK B [Blnk ] [Blnk ] [Blnk ] [Blnk ] [Blnk ] [Blnk ] [Blnk ] [Blnk ]
DEK A [Blnk ] [Blnk ] [Blnk ] [Blnk ] [Blnk ] [Blnk ] [Blnk ] [Blnk ]
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP ADD DELETE TOP EXIT
DEK BOX DEK BOX
