209
SECURE Options From the MAIN MENU, press F4, F6, F3 and then F6 to access this
screen.
This screen can be accessed only when a radio equipped with SECURE
hardware has been read. This screen permits access to SECURE
parameters linked to the current personality. Press Tab to select the
desired field, or press the desired function key (F1 - F10). If a field is
highlighted, use the UP/DOWN arrow keys to select the desired choice
or value.
Function Key Descriptions
F3 - PREV PERS Accesses the previous personality.
F4 - NEXT PERS Accesses the next personality.
Field Definitions
Personality Use the UP/DOWN arrow keys to select the desired conventional
personality. The number may also be entered directly.
Note: Refer to the Radio Catalog Sheet for the maximum
number of personalities allowed for this model.
Secure/Clear Strapping Use the UP/DOWN arrow keys to select the SECURE/Clear strapping
for this personality. This field configures the personality’s transmit
mode. If this field is set to Clear or SECURE, the current personality is
forced to that particular transmit mode. When set to Select, the user is
allowed to select the SECURE or Clear transmit modes via the radio’s
two-position concentric switch.
The factory default is Select (if switch is programmed for SECURE Tx
Select).
DFCF
MOTOROLA Radio Service Software Use UP/DOWN Arrows to Select Choice.
MCS Model:
MAIN:CHANGE/VIEW:CONV:PERS:SECURE
Personality........1 CONVENTIONAL SECURE PERSONALITY
-------------------------------
Secure/Clear Strapping.................Secure
XL Transmit.......................... Enabled
Scan Holdoff Strapping...................Both
Rx Modulation.................2 Level Receive
Proper Code Detect....................Enabled
Echo Mute Time (ms)........................ 0
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP PREV NEXT EXIT
PERS PERS
