195
VRM500 Trunk
Options
From the MAIN MENU, press F4 thrice, F9 and then F7 to access this
screen.
This screen will vary depending on whether you have enabled VRM100 or
VRM500 operation for the radio and the model of the current radio codeplug.
This screen will display fields relating to VRM500 operation only if
VRM500 operation has been enabled. In order to access the VRM500
TRUNK OPTIONS screen, the VRM500 field on the RADIO WIDE OPTIONS
screen (F4/F3/F2) must be set to Enabled. (For help information on the
VRM100 TRUNK OPTIONS screen, refer to page 192.)
This screen allows you to define and modify VRM500 radio options.
Press Tab to select the desired field, or press the desired function key
(F1 - F10). If a field is highlighted, use the UP/DOWN arrow keys to
select the desired choice or value.
Field Definitions
VRM500 Pager Individual ID This field will be visible only if VRM500 operation has been enabled for the
radio. (Refer to dependencies detailed in the screen description above.) Enter
the Trunking Pager ID. This value represents the Trunking Pager ID of
the radio unit which serves as the Robin pager in the VRM500 system.
The Robin pager is used to page the radio on the Trunking system, to
request it to go to Data mode using Call Alert signalling.
The default is 1.
VRM500 Deaffiliation This field will be visible only if VRM500 operation has been enabled for the
radio. (Refer to dependencies detailed in the screen description above.) If the
Affiliation Type field on the TRUNKING SYSTEM screen (F4/F4/F3) is set
to On PTT, the setting for this field will be forced to Disabled. If the
Affiliation Type field is set to Automatic, this field will be set to Enabled and
you can set this field to Enabled or Disabled.
Use the UP/DOWN arrow keys to enable/disable deaffiliation from the
Trunking system before the radio enters the VRM500 data mode.
The default is Disabled.
DDDIG
MOTOROLA Radio Service Software
MCS Model:
...TRUNKING:PERS:OPT:VRM500
Personality........1
VRM500 TRUNK OPTIONS
--------------------
VRM500 Pager Individual ID..........1
VRM500 Deaffiliation.........Disabled
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP EXIT
