68
Controller Board
Initialization
From the MAIN MENU, press F2 and then F9 to access the
CONTROLLER BOARD INITIALIZATION screen.
This screen can be accessed from the SERVICE MENU only when a CBI-
programmed radio is connected to the computer via the RIB. If not, the RSS
will display an error message. This screen allows you to transfer codeplug
information from the computer to the radio codeplug. Enter a valid
serial number and press F8 to proceed.
Note: A CBI radio and RIB must be properly connected to the
computer and the power turned on before you press F8.
Note: If the radio connected to the RIB is NOT a CBI-initialized
radio and you press F9 from the SERVICE MENU, the RSS will
display the following pop-up message: “!!!Warning!!! The radio
attached to the RIB is not a CBI-initialized radio.”
BI
MOTOROLA Radio Service Software
MCS Model:
MAIN:SERVICE:CBI
CONTROLLER BOARD INITIALIZATION
-------------------------------
Serial Number............###ABC?###
Model Number...........XXXXXXXXXXXX
FLASHcode.............XXXXX-XXXXX-X
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP PROGRAM EXIT
RADIO
!
Caution
DO NOT turn off the radio or disconnect the radio
from the computer while it is attempting to program
the codeplug. Interrupting the programming process
will destroy codeplug contents and completely disable
the radio.
