230
MDC System
Options
From the MAIN MENU, press F4, F6, F4, F3 and then F9 to access this
screen.
The settings shown on this screen apply only to the MDC system numerically
identified on the screen.This screen contains more options for MDC
systems. Press Tab to select the desired field, or press the desired
function key (F1 - F10). If a field is highlighted, use the UP/DOWN
arrow keys to select the desired choice or value.
Function Key Descriptions
F3 - PREV SYS Accesses the previous system.
F4 - NEXT SYS Accesses the next system.
F9 - MDC SYS REMOTE MDC SYS REMOTE - is used to change and view parameters associated
with MDC System Remote Monitor/Radio Trace features.
Field Definitions
MDC System Use the UP/DOWN arrow keys to change the MDC system or directly
enter the system number.
System Pretime (ms) Use the UP/DOWN arrow keys to choose a value or enter the desired
value directly. This is the amount of pre-time used before the first MDC
packet is transmitted. If an RAC packet is transmitted, then the system
pre-time is used before the first MDC packet after the RAC packet.
Valid entries range from 0 (zero) to 6350 ms in 50-ms increments.
The default is 400.
Preamble During Pretime Use the UP/DOWN arrow keys to enable/disable the preamble
sequence which will precede voice transmissions.
The default is Disabled.
DFDCI
MOTOROLA Radio Service Software Enter or Scroll to Select Value.
MCS Model:
...CONV:MDC:SYSTEMS:OPTIONS
MDC System.........1
MDC SYSTEM OPTIONS
------------------
Emergency
System Pretime (ms)...........500 Polite Retries..................5
Preamble During Pretime...Enabled Impolite Retries...............15
Inter-Packet Time (ms)........100 Emer Prio Tx Inhibit......Enabled
Limited Patience (sec).........60 Emer Limited Patience (sec)...60
Global Tx Multiplier..... Enabled
DOS (Data Squelch)........Enabled Tx Multiplier...................1
Operation...........1200/1800 Hz RAC (Repeater Access Code)
Coast Time (ms)...........267.00 Pretime (ms).................200
Sel Call Reset.......Auto w/ Carr Ack Alert Tone...........Enabled
Auto Reset Time (sec)..........5 Preambles......................5
Sidetone................ Enabled
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP PREV NEXT MDC SYS EXIT
SYS SYS REMOTE
