Main Menu The MAIN MENU is the top level of the program from which all
function selections start. All selections are made using the function
keys which are labeled F1 through F10 on the keyboard. All other
menus allow you to press the Esc key to return to the MAIN MENU.
For any problems not covered by this manual or the Radio Service Manual,
contact your local Motorola field technical representative.
Function Key Descriptions
F1 - HELP Provides additional information on this screen. Generic help is
available within any help screen in the form of the MORE HELP
function.
F2 - SERVICE A radio must be connected to your computer using a RIB and cables and the
radio turned on before you will be permitted to access the service screens.
Brings up a multi-level menu that enables access to screens from which
radio service alignments are performed.
Note: If the radio attached to the computer via the RIB is a CBI-
initialized radio, you will have to initialize the controller board
and specify the serial number from the CONTROLLER BOARD
INITIALIZATION screen (F2/F9). This process must be
completed if the new CBI controller board is to function
properly.
F3 - GET/SAVE Brings up a menu through the sub-menus of which you can read
codeplug data from a radio and/or retrieve archived codeplug data
from a diskette/hard disk. GET/SAVE functions are also used to
program edited codeplug data back into the radio and create archive
files on disk.
F4 - CHANGE/VIEW A codeplug must be loaded into the computer’s memory using GET/SAVE
functions before CHANGE/VIEW functions can be accessed. Brings up a
multi-level menu that is used to change or view codeplug features and
option configurations.
MOTOROLA Radio Service Software Select Function F1 - F10.
MCS Model:
No System Keys Found.
MAIN
MAIN MENU
---------
F1 - HELP
F2 - SERVICE: Alignment (Requires RIB)
F3 - GET/SAVE/PROGRAM/CLONE Codeplug Data from/to Disk/Radio
F4 - CHANGE/VIEW Radio Codeplug Data
F5 - PRINT Radio Codeplug Data
F6 - FILE Maintenance
F7 -
F8 - FLASHport Upgrade
F9 - SETUP Computer Configuration
F10 - Exit Radio Service Software, Return to DOS
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP SERVICE GET CHANGE PRINT FILE FLASHport SETUP EXIT
MENU SAVE VIEW DATA MAINT UPGRADE MENU TO DOS
