SECURE Transmit
Deviation
From the MAIN MENU, press F2 twice and then F8 to access the
SECURE TRANSMIT DEVIATION screen.
Secure Transmit Deviation should be checked whenever the radio is serviced
and must be adjusted after any modulation circuitry is replaced.
Refer to your Radio Service Manual for the SECURE Transmit
Deviation procedure.
Programming Procedure 1. Press Tab to select the desired field, or press the desired function
key.
2. If a field is selected, press the UP/DOWN arrow keys to select the
desired choice or value.
Function Key Descriptions
F6 - TOGGLE PTT Alternately keys and de-keys the radio being serviced.
F8 - PROGRAM VALUE Programs the selected value into the radio.
Field Definitions
New Softpot Value This is the softpot value for SECURE Transmit Deviation. The status
bar shows the relationship between this setting and the minimum and
maximum settings.
BBH
MOTOROLA Radio Service Software Use UP/DOWN Arrows To Adjust Softpot.
MCS Model:
...SECURE TRANSMIT DEVIATION
SECURE TRANSMIT DEVIATION
-------------------------
Frequency Current Value
--------- -------------
136.0125 110 New Softpot Value.....110
Transmitter..Off
0 127
MIN |----+----+----+----+----+----+----+----+----+----+X---+----| MAX
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP TOGGLE PROGRAM EXIT
PTT VALUE
!
Caution
This procedure should be attempted only by qualified
service personnel. Failure to perform alignment
procedures properly may result in seriously degraded
radio or system performance.
