243
Quik-Call II System From the MAIN MENU, press F4, F6, F7 and then F4 to access this
screen.
This screen allows you to change/view the parameters that pertain to
a Quick-Call system. Press Tab to select the desired field, or press the
desired function key (F1 - F10). If a field is highlighted, use the UP/
DOWN arrow keys to select the desired choice or value.
Function Key Descriptions
F2 - ADD SYS Adds a Quik-Call system.
F3 - PREV SYS Accesses the previous Quik-Call system.
F4 - NEXT SYS Accesses the next Quik-Call system.
F5 - DELETE SYS Deletes the current Quik-Call system. You will be prompted for
confirmation before the system is actually deleted.
F9 - MORE OPTIONS A system or FTR key is required to access this screen. Brings up a screen
which contains more Quik-Call options.
Field Definitions
System Use the UP/DOWN arrow keys to select the desired Quik-Call II
system. You may also enter a number directly or make a selection using
the F3/F4 function keys. The radio may have a maximum number of 15
systems.
System Signalling Type Use the UP/DOWN arrow keys to scroll through the available
selections. This field dictates the System Signalling Type to be used. It
affects the values in the Code (A, B, C, D) fields. Available choices are:
Motorola, GE, Plectron, and Federal.
The default is Motorola.
DFGD
MOTOROLA Radio Service Software Use UP/DOWN Arrows to Select Option.
MCS Model:
...CONV:AUX:QUIK-CALL II SYSTEM
System.............1
QUIK-CALL II SYSTEM
-------------------
System Signalling Type...Motorola Decoder Option.... (1) A-B, (2) C
Signalling Muting Type........AND Long Tone Duration (sec)......4.0
Initial Squelch Type...Quik Call
Reset Type...................Auto Tone Freq (Hz) Code
Auto Reset Carr Ovrd.....Enabled
Auto Reset Duration (sec)......5 A 288.5 138
Decoder 1 Call Type....Individual B 600.9 121
Decoder 2 Call Type.........Group C 1950.0 13
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
HELP ADD PREV NEXT DELETE MORE EXIT
SYS SYS SYS SYS OPTIONS
