- 311 -
9. Operating Management/ Specifications
• Use extra care when handling the image drum (the green cylinder), because it is fragile.
• Do not expose the image drum to direct sunlight or strong light (approximately 1,500 lux or more). Even under room
lighting, do not leave the image drum for five minutes or more.
1
Turn the machine off.
Turning the Machine On or Off (User's Manual)
2
Unplug all the cables.
•
Power cord
•
LAN or USB cable
•
Telephone cable
3
Remove any paper from the paper trays.
4
If the optional additional tray unit is installed, remove the 2 lock pieces.
5
Lift up the machine to remove the additional tray unit.
6
Attach the packing material to the machine.
Transporting This Machine
Injury may result.
Lift this machine by 2 persons, because it weighs approximately 31 kg.
Burns may result.
Do not touch the fuser, because it is very hot.
To Next Page
