5.3.13 Spectracom Format 9
Format 9 provides Day-of-Year and Time information.
E x a m p l e m e s s a g e :
<SOH>DDD:HH:MM:SSQ<CR><LF>
Where:
SOH Start of header (ASCII Character 1)
DDD Day of Year (001-366)
: Colon Separator
HH Hours (00-23)
MM Minutes (00-59)
SS Seconds (00-59) (00-60 for leap second)
Q Time Sync Status [as INPUT]
space = SYNC
‘.’ = SYNC
‘*’=NOT IN SYNC
‘#’ = NOT IN SYNC
“?” = NOT IN SYNC
Q Time Sync Status [as OUTPUT]
space = Time error is less than time quality flag 1's threshold (TFOM < or = 3)
“.” = Time error has exceeded time quality flag 1's threshold (TFOM = 4)
“*” = Time error has exceeded time quality flag 2's threshold (TFOM = 5)
“#” = Time error has exceeded time quality flag 3's threshold (TFOM = 6)
“?” = Time error has exceeded time quality flag 4's threshold OR a reference source is unavail-
able (TFOM >=7)
CR Carriage Return (ASCII Character 13)
LF Line Feed (ASCII Character 10)
The leading edge of the first character (CR) marks the on-time point of the data stream.
5.3.13.1 Format 9S
Format 9S is a variation of ASCII Format 9 that uses Sysplex compatible fields indicating
sychronization status:
