Left Expansion Area
You can select from the following options.
FZ-VBR401 FZ-VDM401 FZ-VDM402 FZ-VBD401 FZ-V2S400 FZ-V2S401 FZ-VSC402
Barcode
Reader
DVD MULTI Drive
Pack
DVD-ROM Drive
Pack
Blu-ray Disc Drive
Pack
SSD Pack (512
GB)
SSD Pack (1
TB)
Smart Card
Reader
Inserting an option to the left expansion area
1. Turn off the computer and disconnect the AC adaptor.
IMPORTANT
l
We recommend that you turn off the computer completely the following.
1.
Click (Start) - [Settings] - [System] - [Recovery].
2. Click [Restart now] in “Advanced startup”.
3. Click [Restart now] on the “We’ll restart your device so save your work” screen.
4. Click [Turn off your PC].
2.
Remove the battery pack. ( Replacing the Battery Pack)
<When using second battery pack>
l
Remove the second battery pack. ( Replacing the Battery Pack)
3. While sliding the latch (A) to the arrow direction, open the cover (B).
4. Insert an option to the left expansion area.
l
If an option has not been inserted, proceed to step 3.
1. Remove the screw (C) and slide the latch (D) until the orange-colored sign appears in the indicator (E).
Use the PH 1 (PH #1) screwdriver.
2. Pull the tab (F) to pull out an option.
To Next Page
