SSD Pack
Attaching/Detaching the SSD pack
You can replace the SSD pack.
IMPORTANT
l
Back up all the important data before detaching the SSD pack.
l
Carefully attach/detach the SSD pack since the SSD pack is extremely sensitive to shock. Note that static electricity may affect
some internal components.
1. Turn off the computer and disconnect the AC adaptor.
l
Do not use sleep or hibernation.
Perform the following steps to turn off the computer.
1.
Click (Start) - [Settings] - [System] - [Recovery].
2. Click [Restart now] in “Advanced startup”.
3. Click [Restart now] on the “We’ll restart your device so save your work” screen.
4. Click [Turn off your PC].
2.
Remove the battery pack. ( Replacing the Battery Pack)
<When using second battery pack>
l
Remove the second battery pack. ( Replacing the Battery Pack)
3. Attach/Detach the SSD pack.
l
To detach
1. Slide the latch (A) to the arrow direction.
2. Slide the cover (B) to the arrow direction.
3. Open the cover (B).
To Next Page
