6. Press the [Menu] key to return to the initial screen.
7. Print a configuration page to confirm the settings.
• For details about printing the configuration page, see p.44 "Test Printing".
Configuring Network Settings When Using NetWare
To use NetWare, select the appropriate NetWare frame type from the following.
•
Auto Select
• Ethernet II
• Ethernet 802.2
• Ethernet 802.3
• Ethernet SNAP
• Usually, you can use the default (Auto Select). When you first select [Auto Select], the frame type
detected
by the printer is adopted. However, if your network can use more than two frame types, the
printer may fail to select the correct frame type with [Auto Select] selected. In this case, select the
preferred frame type.
1. Press the [Menu] key.
CEC216
2. Press the [ ] or [ ] key to select [Host Interface], and then press the [OK] key.
5. Configuration
80
5
