Using Explicit Messaging 6-5
PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
ControlLogix Example Ladder Logic Program to Write Single
Parameter
A Set Attribute Single message is used to write to a single parameter.
This write message example writes a value to the 32-bit REAL (floating
point) parameter 535 - [Accel Time 1] in a PowerFlex 750-Series drive.
Table 6.B Example Controller Tags for Write Single Parameter Messaging
Program
Figure 6.4 Example Ladder Logic Explicit Messaging Program for Write Single
Operand Controller Tags for Write Single Message Data Type
XIC Execute_Single_Write_Message BOOL
MSG Single_Write_Message MESSAGE
To Next Page
