Using the I/O 5-3
PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
PLC-5, SLC 500, and MicroLogix 1100 Controller Image
The I/O image for the PLC-5, SLC 500, and MicroLogix 1100
controller changes depending on how many of the drive’s sixteen 32-bit
Datalinks are used.
Table 5.B PLC-5, SLC 500, and MicroLogix 1100 I/O Image for PowerFlex
750-Series Drives (32-bit Logic Command/Status, Reference/
Feedback, and Datalinks)
TIP: Since PLC-5, SLC 500, and MicroLogix 1100 controllers are
16-bit devices, each 32-bit word for the Logic Command/Status,
Reference/Feedback, and any used Datalinks will consume two
contiguous words (Least and Most Significant) in the controller’s I/O
image. Table 5.B
shows the I/O for a drive using all 32-bit Datalinks.
Word Output I/O Word Input I/O
0 Logic Command (LSW) 0 Logic Status (LSW)
1 Logic Command (MSW) 1 Logic Status (MSW)
2 Reference (LSW) 2 Feedback (LSW)
3 Reference (MSW) 3 Feedback (MSW)
4 DL From Net 01 (LSW) 4 DL To Net 01 (LSW)
5 DL From Net 01 (MSW) 5 DL To Net 01 (MSW)
6 DL From Net 02 (LSW) 6 DL To Net 02 (LSW)
7 DL From Net 02 (MSW) 7 DL To Net 02 (MSW)
8 DL From Net 03 (LSW) 8 DL To Net 03 (LSW)
9 DL From Net 03 (MSW) 9 DL To Net 03 (MSW)
10 DL From Net 04 (LSW) 10 DL To Net 04 (LSW)
11 DL From Net 04 (MSW) 11 DL To Net 04 (MSW)
12 DL From Net 05 (LSW) 12 DL To Net 05 (LSW)
13 DL From Net 05 (MSW) 13 DL To Net 05 (MSW)
14 DL From Net 06 (LSW) 14 DL To Net 06 (LSW)
15 DL From Net 06 (MSW) 15 DL To Net 06 (MSW)
16 DL From Net 07 (LSW) 16 DL To Net 07 (LSW)
17 DL From Net 07 (MSW) 17 DL To Net 07 (MSW)
18 DL From Net 08 (LSW) 18 DL To Net 08 (LSW)
19 DL From Net 08 (MSW) 19 DL To Net 08 (MSW)
20 DL From Net 09 (LSW) 20 DL To Net 09 (LSW)
21 DL From Net 09 (MSW) 21 DL To Net 09 (MSW)
22 DL From Net 10 (LSW) 22 DL To Net 10 (LSW)
23 DL From Net 10 (MSW) 23 DL To Net 10 (MSW)
24 DL From Net 11 (LSW) 24 DL To Net 11 (LSW)
25 DL From Net 11 (MSW) 25 DL To Net 11 (MSW)
26 DL From Net 12 (LSW) 26 DL To Net 12 (LSW)
27 DL From Net 12 (MSW) 27 DL To Net 12 (MSW)
28 DL From Net 13 (LSW) 28 DL To Net 13 (LSW)
29 DL From Net 13 (MSW) 29 DL To Net 13 (MSW)
30 DL From Net 14 (LSW) 30 DL To Net 14 (LSW)
31 DL From Net 14 (MSW) 31 DL To Net 14 (MSW)
32 DL From Net 15 (LSW) 32 DL To Net 15 (LSW)
33 DL From Net 15 (MSW) 33 DL To Net 15 (MSW)
34 DL From Net 16 (LSW) 34 DL To Net 16 (LSW)
35 DL From Net 16 (MSW) 35 DL To Net 16 (MSW)
