PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
Chapter 3
Configuring the Adapter
This chapter provides instructions and information for setting the
parameters to configure the embedded EtherNet/IP adapter.
For a list of parameters, refer to Appendix B, Adapter Parameters. For
definitions of terms in this chapter, refer to the Glossary
.
Configuration Tools
The embedded EtherNet/IP adapter stores parameters and other
information in its own non-volatile memory. You must, therefore,
access the adapter to view and edit its parameters. The following tools
can be used to access the adapter parameters:
Using the Enhanced
PowerFlex 7-Class HIM
If your drive has an enhanced PowerFlex 7-Class HIM, it can be used to
access parameters in the adapter. For details on viewing and editing
parameters, refer to the Enhanced PowerFlex 7-Class HIM User
Manual (publication 20HIM-UM001).
Topic Page
Configuration Tools
3-1
Using the Enhanced PowerFlex 7-Class HIM 3-1
Using BOOTP 3-2
Setting the IP Address, Subnet Mask, and Gateway Address 3-5
Setting the Data Rate 3-7
Selecting Master-Slave or Peer-to-Peer 3-8
Setting a Fault Action 3-14
Setting Web Access Control 3-16
Resetting the Adapter 3-17
Restoring Adapter Parameters to Factory Defaults 3-17
Viewing the Adapter Status Using Parameters 3-18
Flash Updating the Adapter 3-18
Tool Refer to…
Enhanced PowerFlex 7-Class HIM Enhanced PowerFlex 7-Class HIM User Manual
BOOTP Server page 3-2
DriveExplorer Software
(version 6.01 or higher)
http://www.ab.com/drives/driveexplorer, or
DriveExplorer online help (installed with the software)
DriveExecutive Software
(version 5.01 or higher)
http://www.ab.com/drives/drivetools, or
DriveExecutive online help (installed with the software)
