PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
Chapter 7
Troubleshooting
This chapter provides information for diagnosing and troubleshooting
potential problems with the adapter and network.
Understanding the Status
Indicators
The adapter has two status indicators. They can be viewed with the HIM
bezel closed or open (Figure 7.1
).
Figure 7.1 Status Indicators
Topic Page
Understanding the Status Indicators
7-1
ENET Status Indicator 7-2
LINK Status Indicator 7-2
Viewing Adapter Diagnostic Items 7-3
Viewing and Clearing Events 7-5
➊
➋
➊
➋
Item
Status
Indicator
Description Page
➊
ENET EtherNet/IP Connection Status 7-2
➋
LINK EtherNet/IP Transmit Status 7-2
Embedded EtherNet/IP adapter indicators
on main control board in drive control pod.
Indicators shown with HIM bezel
closed and drive cover installed.
