Viewing the Adapter Web Pages 8-3
PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
Navigation Menu on Adapter Web Pages
The navigation menu appears on the left side of all adapter web pages,
including its Home page. The navigation menu consists of links and
link folders which can be expanded or minimized. The following table
shows all navigation menu links and link folders:
Information on Adapter Home Page
The adapter Home Page displays the following information for the host
drive and adapter:
Link/Folder Description
Home link Click this link to view the adapter’s Home Page (Figure 8.1
).
Process Display link Click this link to view the Host’s Process Display pop-up window
(Figure 8.2
)
TCP/IP configuration link Click this link to view the adapter’s TCP/IP Configuration web page
showing information about the TCP/IP configuration, such as the
adapter’s IP address and the number of packets being sent.
Figure 8.3
shows an example TCP/IP Configuration web page.
Configure e-mail
notification link
Click this link to view the adapter’s Configure E-mail Notification
web page (Figure 8.4
) to configure the adapter to send automatic
e-mail messages. An example e-mail message is shown in
Figure 8.5.
Browse DPI devices folder Click this folder to expand and view the Port folders for all present
DPI devices, including the drive, adapter, and other DPI devices
connected to the drive such as a HIM.
Port x folders Click a respective Port folder to expand and view its device’s
various links which take you to related information pages. For Port
00 (PowerFlex 755 Drive) example information pages, see
Figure 8.6
, Figure 8.7, and Figure 8.8.
Online user manuals link Click this link to view Rockwell Automation’s web page with
documentation for drives and other devices.
Software tools Web site
link
Click this link to view Allen-Bradley’s web page with information
about software tools such as DriveExplorer and DriveExecutive.
Launch my DriveExplorer
software link
Click this link to launch the DriveExplorer software already installed
on your PC.
Launch my DriveExecutive
software link
Click this link to launch the DriveExecutive software already
installed on your PC.
E-mail technical support
link
Click this link to view a new e-mail message window to send a
message to Allen-Bradley’s Technical Support Team.
Information for Description
Host Drive • Revision
• Status
• Commanded Direction
• Rotation Direction
• Process Status
EtherNet/IP Embedded
Adapter
• IP Address
• Ethernet Address (MAC)
• Serial Number
• Adapter Status
• I/O Connection Status
