Using the I/O 5-15
PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
Table 5.D PLC-5, SLC 500, and MicroLogix 1100 Data Table Addresses for
PowerFlex 750-Series Drives
Data Table
Address
Description
N20:0 Control Timeout
N20:1 Logic Status (LSW, see Appendix D
)
N20:2 Logic Status (MSW, see Appendix D
)
N20:3 Speed Feedback LSW
N20:4 Speed Feedback MSW
N20:5 Value of parameter assigned to adapter Parameter 17 [DL To Net 01] LSW
N20:6 Value of parameter assigned to adapter Parameter 17 [DL To Net 01] MSW
N20:7 Value of parameter assigned to adapter Parameter 18 [DL To Net 02] LSW
N20:8 Value of parameter assigned to adapter Parameter 18 [DL To Net 02] MSW
N20:9 Value of parameter assigned to adapter Parameter 19 [DL To Net 03] LSW
N20:10 Value of parameter assigned to adapter Parameter 19 [DL To Net 03] MSW
N20:11 Value of parameter assigned to adapter Parameter 20 [DL To Net 04] LSW
N20:12 Value of parameter assigned to adapter Parameter 20 [DL To Net 04] MSW
N20:13 Value of parameter assigned to adapter Parameter 21 [DL To Net 05] LSW
N20:14 Value of parameter assigned to adapter Parameter 21 [DL To Net 05] MSW
N20:15 Value of parameter assigned to adapter Parameter 22 [DL To Net 06] LSW
N20:16 Value of parameter assigned to adapter Parameter 22 [DL To Net 06] MSW
N20:17 Value of parameter assigned to adapter Parameter 23 [DL To Net 07] LSW
N20:18 Value of parameter assigned to adapter Parameter 23 [DL To Net 07] MSW
N20:19 Value of parameter assigned to adapter Parameter 24 [DL To Net 08] LSW
N20:20 Value of parameter assigned to adapter Parameter 24 [DL To Net 08] MSW
N20:21 Value of parameter assigned to adapter Parameter 25 [DL To Net 09] LSW
N20:22 Value of parameter assigned to adapter Parameter 25 [DL To Net 09] MSW
N20:23 Value of parameter assigned to adapter Parameter 26 [DL To Net 10] LSW
N20:24 Value of parameter assigned to adapter Parameter 26 [DL To Net 10] MSW
N20:25 Value of parameter assigned to adapter Parameter 27 [DL To Net 11] LSW
N20:26 Value of parameter assigned to adapter Parameter 27 [DL To Net 11] MSW
N20:27 Value of parameter assigned to adapter Parameter 28 [DL To Net 12] LSW
N20:28 Value of parameter assigned to adapter Parameter 28 [DL To Net 12] MSW
N20:29 Value of parameter assigned to adapter Parameter 29 [DL To Net 13] LSW
N20:30 Value of parameter assigned to adapter Parameter 29 [DL To Net 13] MSW
N20:31 Value of parameter assigned to adapter Parameter 30 [DL To Net 14] LSW
N20:32 Value of parameter assigned to adapter Parameter 30 [DL To Net 14] MSW
N20:33 Value of parameter assigned to adapter Parameter 31 [DL To Net 15] LSW
N20:34 Value of parameter assigned to adapter Parameter 31 [DL To Net 15] MSW
N20:35 Value of parameter assigned to adapter Parameter 32 [DL To Net 16] LSW
N20:36 Value of parameter assigned to adapter Parameter 32 [DL To Net 16] MSW
N20:37 Logic Command (LSW, see Appendix D
)
N20:38 Logic Command (MSW, see Appendix D
)
N20:39 Speed Reference LSW
N20:40 Speed Reference MSW
N20:41 Value of parameter assigned to adapter Parameter 01 [DL From Net 01] LSW
N20:42 Value of parameter assigned to adapter Parameter 01 [DL From Net 01] MSW
N20:43 Value of parameter assigned to adapter Parameter 02 [DL From Net 02] LSW
N20:44 Value of parameter assigned to adapter Parameter 02 [DL From Net 02] MSW
N20:45 Value of parameter assigned to adapter Parameter 03 [DL From Net 03] LSW
N20:46 Value of parameter assigned to adapter Parameter 03 [DL From Net 03] MSW
N20:47 Value of parameter assigned to adapter Parameter 04 [DL From Net 04] LSW
N20:48 Value of parameter assigned to adapter Parameter 04 [DL From Net 04] MSW
N20:49 Value of parameter assigned to adapter Parameter 05 [DL From Net 05] LSW
N20:50 Value of parameter assigned to adapter Parameter 05 [DL From Net 05] MSW
