Getting Started 1-5
PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
Quick Start
This section is provided to help experienced users quickly start using
the embedded EtherNet/IP adapter. If you are unsure how to complete a
step, refer to the referenced chapter.
Step Action Refer to…
1 Review the safety precautions for the adapter. Throughout This Manual
2 Verify that the PowerFlex drive is properly installed. PowerFlex 750-Series
AC Drive Installation
Instructions
3 Set the adapter IP address.
A. When using the adapter switches, set the IP address.
When using a BOOTP server or adapter parameters to
set the IP address, first perform Step 3B and all of Step 4.
Then proceed with Step 5.
B. Verify that the PowerFlex drive is not powered. Then,
connect the embedded EtherNet/IP adapter to the
network using an Ethernet cable.
Chapter 2
,
Installing the Adapter
4 Apply power to the drive.
A. Replace the drive cover or close the drive door.
B. The embedded EtherNet/IP adapter receives power from
the drive. Apply power to the drive. The status indicators
should be green. If they flash red, there is a problem.
Refer to Chapter 7
, Troubleshooting.
C. Configure/verify key drive parameters.
Chapter 2
,
Installing the Adapter
5 Configure the adapter for your application.
Set embedded EtherNet/IP adapter parameters for the
following functions as required by your application:
• IP address, subnet mask, and gateway address (only
when not using adapter switches)
• Data rate
• I/O configuration
• Master-Slave or Peer-to-Peer hierarchy
• Fault actions
• Web enable/features
Chapter 3
,
Configuring the Adapter
6 Configure the controller to communicate with the
adapter.
Use a controller configuration tool such as RSLogix to
configure the master on the EtherNet/IP network to
recognize the embedded EtherNet/IP adapter and drive.
Chapter 4,
Configuring the I/O
7 Create a ladder logic program.
Use a controller configuration tool such as RSLogix to create
a ladder logic program that enables you to:
• Control the embedded EtherNet/IP adapter and drive
using I/O.
• Monitor or configure the drive using Explicit messages.
Chapter 5
,
Using the I/O
Chapter 6,
Using Explicit Messaging
To Next Page
