Configuring the Adapter 3-15
PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
Figure 3.16 Edit Fault Action HIM Screens
Changes to these parameters take effect immediately. A reset is not
required.
Setting the Fault Configuration Parameters
If you set Parameter 54 - [Comm Flt Action], 55 - [Idle Flt Action],
56 - [Peer Flt Action] or Parameter 57 - [Msg Flt Action] to “Send
Flt Cfg,” the values in the following parameters are sent to the drive
after an I/O communications fault, idle fault, Peer I/O fault, and/or
explicit messaging for drive control fault occurs. You must set these
parameters to values required by your application.
Changes to these parameters take effect immediately. A reset is not
required.
ESC

ENTER
Stopped
0.00 Hz
AUTO
F
▲▼
Edit Comm Flt Action
Fault 0
0<<4
ESC

ENTER
Stopped
0.00 Hz
AUTO
F
▲▼
Edit Idle Flt Action
Fault 0
0<<4
ESC

ENTER
Stopped
0.00 Hz
AUTO
F
▲▼
Edit Msg Flt Action
Fault 0
0<<4
ESC

ENTER
Stopped
0.00 Hz
AUTO
F
▲▼
Edit Peer Flt Action
Fault 0
0<<4
Parameter Description
Parameter 58 - [Flt Cfg Logic] A 32-bit value sent to the drive for Logic Command.
Parameter 59 - [Flt Cfg Ref] A 32-bit REAL (floating point) value sent to the drive for
Reference.
Parameter 60 - [Flt Cfg DL 01]
through
Parameter 75 - [Flt Cfg DL 16]
A 32-bit integer value sent to the drive for a Datalink. If the
destination of the Datalink is a REAL (floating point)
parameter, you must convert the desired value to the binary
representation of the REAL value. (An internet search of “hex
to float” provides a link to a tool to do this conversion.)
