C-34 EtherNet/IP Objects
PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
TCP/IP Interface Object
Class Code
Services
Instances
The adapter supports one instance of the TCP/IP Interface object.
Class Attributes
Instance Attributes
Hexadecimal Decimal
0xF5 245
Service Code
Implemented for:
Service NameClass Instance
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Number Description
0 Class Attributes
1 Object Attributes
Attribute ID Access Rule Name Data Type Description
1 Get Revision UINT The revision of this object
Attribute ID Access Rule Name Data Type Description
1 Get Status of TCP/IP
Network Interface
UDINT 0 = Not configured
1 = Valid configuration
2 to 15 = Reserved
2 Get Configuration Capability UDINT Bit | Value (0 = False, 1 = True)
0 = Supports BOOTP
1 = DNS Client (able to resolve host names
by query to DNS server)
2 = DHCP Client (able to obtain network
configuration through DHCP)
3 = DHCP-DNS Update (able to send its host
name in the DHCP request)
4 = Configuration Settable (able to set the
network configuration via TCP/IP object)
5 to 31 = Reserved
3 Set Configuration Control UDINT Bit | Value
1 – 3 = Startup configuration
0 = Use configuration saved in NVS
1 = Obtain configuration via BOOTP
2 = Obtain configuration via DHCP
3 to 15 = Reserved
4 = DNS Enabled (resolves host names by
query to DNS server)
5 to 31 = Reserved
