8-2 Viewing the Adapter Web Pages
PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
2. In the Address box, type the IP address of the adapter, and then
press ENTER. The adapter web Home Page (Figure 8.1
) appears.
Important:Clicking the browser’s Refresh button always
re-displays the Home Page even while viewing another
adapter web page.
Figure 8.1 Adapter Web Home Page Example
Title Bar on Adapter Web Pages
The title bar appears on all adapter web pages, including its Home Page.
It consists of three elements:
Title Bar Element Description
Allen-Bradley logo
(at far left)
This logo is a hyperlink. Click it to view the ab.com web Home Page.
Adapter Title (middle) Shows the adapter type or the title configured by the user (via a HIM,
DriveExecutive or DriveExplorer).
Rockwell Automation
logo (at far right)
This logo is a hyperlink. Click it to view the Rockwell Automation web
Home Page.
