Troubleshooting 7-3
PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
Viewing Adapter Diagnostic
Items
If you encounter unexpected communications problems, the adapter’s
diagnostic items may help you or Rockwell Automation personnel
troubleshoot the problem. Adapter diagnostic items can be viewed
using the enhanced PowerFlex 7-Class HIM, DriveExplorer software
(version 6.01 or higher), or DriveExecutive software (version 5.01 or
higher). For details on viewing diagnostic items using the HIM, refer to
the Enhanced PowerFlex 7-Class HIM User Manual (publication
20HIM-UM001).
Table 7.A Adapter Diagnostic Items
No. Name Description
1 Common Logic Cmd The present value of the Common Logic Command being transmitted to the drive by this adapter.
2 Prod Logic Cmd The present value of the Product Logic Command being transmitted to the drive by this adapter.
3 Reference The present value of the Reference being transmitted to the drive by this adapter.
4 Common Logic Sts The present value of the Common Logic Status being received from the drive by this adapter.
5 Prod Logic Sts The present value of the Product Logic Status being received from the drive by this adapter.
6 Feedback The present value of the Feedback being received from the drive by this adapter.
7 Input Size Size of data transferred from the network to the drive.
8 Output Size Size of data transferred from the drive to the network.
9 DL Fr Net Avail The number of From Net Datalinks currently available to the adapter.
10 DL To Net Avail The number of To Net Datalinks currently available to the adapter.
11 DL Fr Net 01 Val The present value of respective DL From Net xx parameter being transmitted to the drive by this
adapter. (If not using a Datalink, its respective value should be zero.)
12 DL Fr Net 02 Val
13 DL Fr Net 03 Val
14 DL Fr Net 04 Val
15 DL Fr Net 05 Val
16 DL Fr Net 06 Val
17 DL Fr Net 07 Val
18 DL Fr Net 08 Val
19 DL Fr Net 09 Val
20 DL Fr Net 10 Val
21 DL Fr Net 11 Val
22 DL Fr Net 12 Val
23 DL Fr Net 13 Val
24 DL Fr Net 14 Val
25 DL Fr Net 15 Val
26 DL Fr Net 16 Val
27 DL To Net 01 Val The present value of respective DL To Net xx parameter being received from the drive by this
adapter. (If not using a Datalink, its respective value should be zero.)
28 DL To Net 02 Val
29 DL To Net 03 Val
30 DL To Net 04 Val
31 DL To Net 05 Val
32 DL To Net 06 Val
33 DL To Net 07 Val
34 DL To Net 08 Val
35 DL To Net 09 Val
36 DL To Net 10 Val
37 DL To Net 11 Val
38 DL To Net 12 Val
39 DL To Net 13 Val
40 DL To Net 14 Val
41 DL To Net 15 Val
42 DL To Net 16 Val
