Getting Started 1-3
PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
Compatible Products
At the time of publication, the embedded EtherNet/IP adapter is
compatible with Allen-Bradley PowerFlex 750-Series drives.
Required Equipment
Equipment Shipped with the Drive
Since the EtherNet/IP adapter is embedded on the Main Control Board
in the PowerFlex 755 drive, it is always an integral part of the drive and,
therefore, is not shipped with installation instructions.
User-Supplied Equipment
To configure the embedded EtherNet/IP adapter, you must supply:
❑ A small flathead screwdriver
❑ Ethernet cable (for details, refer to the EtherNet/IP Media Planning
and Installation Manual, publication ENET-IN001)
❑ Ethernet switch (for details, refer to the EtherNet/IP Performance
Application Solution, publication ENET-AP001)
❑ Configuration tool, such as:
– Enhanced PowerFlex 7-Class HIM (20-HIM-A6/C6S)
– DriveExplorer (version 6.01 or higher)
– DriveExecutive stand-alone software (version 5.01 or higher) or
bundled with the DriveTools SP suite (version 5.01 or higher)
– BOOTP Server (version 2.1 or higher) for network setup only
❑ Controller configuration software (such as RSLogix 5/500/5000)
❑ A PC connection to the EtherNet/IP network
