C-10 EtherNet/IP Objects
PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
DPI Device Object
Class Code
Services
Instances
The number of instances depends on the number of components in the
device. The total number of components can be read in Instance 0, Class
Attribute 4.
Class Attributes
Hexadecimal Decimal
0x92 146
Service Code
Implemented for:
Service NameClass Instance
0x0E Yes Yes Get_Attribute_Single
0x10 Yes Yes Set_Attribute_Single
Instances (Hex.) (Dec.) Device Example Description
0x0000 – 0x3FFF 0 – 16383 Host Drive 0 Class Attributes (Drive)
0x4000 – 0x43FF 16384 – 17407 Adapter 1 Drive Component 1
0x4400 – 0x47FF 17408 – 18431 Port 1 2 Drive Component 2
0x4800 – 0x4BFF 18432 – 19455 Port 2
… …
0x4C00 – 0x4FFF 19456 – 20479 Port 3 16384 Class Attributes (Adapter)
0x5000 – 0x53FF 20480 – 21503 Port 4 16385 Adapter Component 1
0x5400 – 0x57FF 21504 – 22527 Port 5
… …
0x5800 – 0x5BFF 22528 – 23551 Port 6
0x5C00 – 0x5FFF 23552 – 24575 Port 7
0x6000 – 0x63FF 24576 – 25599 Port 8
0x6400 – 0x67FF 25600 – 26623 Port 9
0x6800 – 0x6BFF 26624 – 27647 Port 10
0x6C00 – 0x6FFF 27648 – 28671 Port 11
0x7000 – 0x73FF 28672 – 29695 Port 12
0x7400 – 0x77FF 29696 – 30719 Port 13
0x7800 – 0x7BFF 30720 – 31743 Port 14
Attribute ID Access Rule Name Data Type Description
0 Get Family Code USINT 0x00 = DPI Peripheral
0x90 = PowerFlex 755
0xA0 = 20-750 Series Option Card
0xFF = HIM
1 Get Family Text STRING[16] Text identifying the device.
2 Set Language Code USINT 0 = English
1 = French
2 = Spanish
3 = Italian
4 = German
5 = Japanese
6 = Portuguese
7 = Mandarin Chinese
8 = Russian
9 = Dutch
10 = Korean
