PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
Appendix C
EtherNet/IP Objects
Appendix C presents information about the EtherNet/IP objects that can
be accessed using Explicit Messages.
For information on the format of
Explicit Messages and example ladder logic programs, refer to
Chapter
6, Using Explicit Messaging.
Supported Data Types
Object
Class Code
Page Object
Class Code
PageHex. Dec. Hex. Dec.
Identity Object
0x01 1 C-2 DPI Alarm Object 0x98 152 C-21
Assembly Object 0x04 4 C-3 DPI Diagnostic Object 0x99 153 C-23
Register Object 0x07 7 C-4 DPI Time Object 0x9B 155 C-25
PCCC Object 0x67 103 C-6 Host DPI Parameter Object 0x9F 159 C-28
DPI Device Object 0x92 146 C-10 TCP/IP Interface Object 0xF5 245 C-34
DPI Parameter Object 0x93 147 C-13 Ethernet Link Object 0xF6 246 C-36
DPI Fault Object 0x97 151 C-19
TIP: Refer to the EtherNet/IP specification for more information about
EtherNet/IP objects. Information about the EtherNet/IP specification is
available on the ODVA web site (http://www.odva.org
).
Data Type Description
BOOL 8-bit value -- low bit is true or false
BOOL[x] Array of n bits
CONTAINER 32-bit parameter value - sign extended if necessary
DINT 32-bit signed integer
INT 16-bit signed integer
LWORD 64-bit unsigned integer
REAL 32-bit floating point
SHORT_STRING Struct of: USINT length indicator (L); USINT[L] characters
SINT 8-bit signed integer
STRINGN Struct of: UINT character length indicator (W); UINT length indicator (L);
USINT[W x L] string data
STRING[x] Array of n characters
STRUCT Structure name only - no size in addition to elements
TCHAR 8 or 16-bit character
UDINT 32-bit unsigned integer
UINT 16-bit unsigned integer
USINT 8-bit unsigned integer
