Digital modules

3.18 Digital input module SM 321; DI 8 x AC 120/230 V ISOL; (6ES7321-1FF10-0AA0)

S7-300 Module data

Manual, 06/2017, A5E00105505-AJ

117

3.18 Digital input module SM 321; DI 8 x AC 120/230 V ISOL;

(6ES7321-1FF10-0AA0)

Order number

6ES7321-1FF10-0AA0

Properties

Properties of the digital input module SM 321; DI 8 x AC 120/230 V ISOL:

● 8 inputs, electrically isolated in groups of 1

● Rated input voltage 120/230 VAC

● Suitable for switches and 2-/3-/4-wire AC proximity switches

Wiring and block diagrams of SM 321; DI 8 x AC 120/230 V ISOL

①

Channel number

②

Status display - green

③

Backplane bus interface
