Siemens SIMATIC User Manual

Analog modules
6.13 Analog output module SM 332; AO 4 x 16 bit; isochrone; (6ES7332-7ND02-0AB0)
S7-300 Module data
456 Manual, 06/2017, A5E00105505-AJ
6.13.1 SM 332; AO 4 x 16 Bit - Output ranges
Introduction
You can configure the outputs for operation as voltage or current outputs, or disable these.
You program the outputs at the "output type" parameter in
STEP 7 .
The output type "Voltage" and output range "± 10 V" are set by default at the module. You
can always use this combination of output type and range without having to program the
SM 332; AO 4 x 16 Bit in
STEP 7 .
Output ranges
You program the output ranges for voltage and current outputs in STEP 7 .
Table 6- 34 Output ranges SM 332; AO 4 x 16 Bit
Selected type of output
Output range
Voltage 1 V to 5 V
0 V to 10 V
± 10 V
Current 0 mA to 20 mA
4 mA to 20 mA
± 20 mA
