A.13 Parameters of analog output module SM 332; AO 8 x 12 Bit
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
577
A.13 Parameters of analog output module SM 332; AO 8 x 12 Bit
Parameter
The table below shows all parameters you can set at analog output module
SM 332; AO 8 x 12 Bit. The comparison shows:
● which parameters you can edit in
STEP 7 , and
● which parameters you can change using SFC 55 "WR_PARM".
Parameters set in
STEP 7 can also be transferred to the module using SFC 56 and SFC 57.
Table A- 32 Parameters of SM 332; AO 8 x 12 Bit
Parameters
Data record num-
ber
Programmable, using ...
... SFC 55
... PG
Diagnostics: Group diagnostics 0 no yes
Diagnostics interrupt enable
1
yes
yes
Reaction to CPU STOP
yes
yes
Output type
yes
yes
Output range
yes
yes
Note
To enable diagnostics interrupts in the user program at data record 1, you first need to
enable diagnostics at data record 0 in
STEP 7 .
